HVAC fin tooling

Air Conditioner Fin Die for condenser and evaporator production.

Sinoak designs air conditioner fin die tooling around fin pitch, tube pattern, collar height, louver design and production speed for HVAC coil factories.

Send air conditioner fin die RFQ
Air conditioner heat exchanger fins for fin die tooling

Typical applications

Air conditioner fin dies are used for indoor and outdoor unit heat exchanger fins, including condenser and evaporator coil production.

Design focus

Fin geometryFin pitch, louver or slit pattern, collar height and fin size.
Tube patternTube diameter, tube spacing, rows and circuit design.
MaterialAluminum fin stock thickness, hardness and surface treatment.
Press matchingDie size, press tonnage, stroke speed and feeding accuracy.

RFQ details to prepare

  • Fin drawing or sample fin photos.
  • Tube diameter, tube pattern and rows.
  • Fin pitch, material thickness and collar height.
  • Press model, target speed and application type.
